This was an excellent demonstration. Thankyou!

Thanks for that Isaac.

I’m pretty sure I’ll need this item, as the door is over 1m tall. Accuride 1319/1316 parallelo set

The door is ~490 mm wide so the depth of the slide will have to be 500 mm, door thickness 16mm, height 1930 mm.

There are CAD files on the site, but I really havent got a clue what format to download for polyboard.

Regards,

Ray.

Thankyou for your patience Isaac.

Please find attached my final copy of the files ready for plans. I have removed the drillings.

On one final note, and I don’t mind if not possible, but I was trying to find a way of importing the haeffelle PIVOT SLIDING DOOR FITTING 506MM – in the Häfele Australia Shop pocket slider into the model to ensure it all worked, however I couldnt find an appropriate format or library item. Do you know if there is a way to import it?

Regards,

Ray.

Hi Isaac,

I’ve updated the plinth. However, cannot fix the drillings, as it doesnt appear the handles are in my libraries. It also doesnt look as though they have any associated drillings on my end. I did have to reinstall on a new computer since first designing this.

I have a question about why the edge of the wall cupboards are showing bolded where they join each other and the filler panel? Not sure what is happening there? Also occurs with the right side of the large cupboard.

Please find the updated design attached.

Regards,

Ray.

Isaac said
Hello Ray, T
Thank you for the request, your drawings look quite good.
After reviewing the files I just wanted to confirm a few small things with you and then I will provide you with the files.
1. I want to confirm that you only want files for the project “Laundry-without-sink-and-bench.pb-proj”
2. In the cabinet “large cupboard”, I have noticed a few small things. Please see the following video for my questions:
[Permission to view this media is denied]
3. As explained in the video, handles have drillings associated with them. I wanted to confirm that you want this and it isn’t just for a visual display.
Sorry for the delay, as soon as I hear back from you I will happily provide you with your files.
Best regards, Isaac


Hi Isaac,

Thankyou for the video, make it easier.

1. yes only need files for the laundry without sink file.

2. The intention is to have the drillings for the shelves either side. Probably only need the front and rear. This applies to both sets of shelves.

this is intended to be a pocket door using the haffelle hinge set. that’s why there is the slim section to the right.

also the plinth panel should stretch between the panels either side of the tall cupboard.

3. Drillings for handles not required as I’m not 100% sure what handles I’ll be using yet.

thankyou so much.

regards,

ray.
